TOSEO Customized Recessed Fire Rated Spotlight Bathroom Square COB
Led Downlight
About Us -- GU10 Downlight Manufacture
Foshan Nanhai Dongxu Lighting Co., Ltd. is a direct lighting
manufacturer with more than 15 years of history. The location is in
Foshan. Built in 2007, the factory covers an area of more than
15,000 square meters and employs more than 400 people. Our products
are GU10 downlight accessories and LED downlight accessories,
including: waterproof downlight, recessed downlight, fireproof
downlight, Trimless downlight. TOSEO's global reach spans the
world, with key markets including Europe, Asia, the Pacific, the
Middle East, South Africa and North Africa. Welcome to contact us,
we hope to maintain cooperation
Quick detail of led Downlight
IP Rating :IP20
Lamp Body Material:Die-casting Alu
Application: Hotel,Showroom,restaurant,Hocme
Color: Black, White, Satin Nickel, Chrome,etc
Warranty: 24 -Months
Size:83xH66mm
Certification: CE, RoHS
Model Number: TD2135
Packaging Details: 20pcs per carton. Master carton size
57.5x29.5x19.5cm. Net weight 6.4kgs. Gross weight8.4kgs
Delivery Time: about 32days20pcs
Payment Terms: L/C, T/T D/P
Description Of GU10 & Led Recessed Downlight
1.IP54
2.Front replace bulb
3.It is easy installing with wall light.
4.There are many color for options, such as matte white, matte
black, sand white, sand black, gold, satin nickel, chrome.
5.Die-casting alu, pure alu, steel & alu.and any material for
options.
Packaging & delivery
1.20pcs per carton. Master carton size 57.5x29.5x19.5cm. Net weight
6.4kgs. Gross weight8.4kgs
2. White inner box,Brown Master carton .
3. OEM available in individual color packaging. In order to better
ensure the safety of your goods, Foshan Port will provide you with
professional, environmental protection, convenient and efficient
packaging services
INSTALLATION INSTRUCTIONS
Turn off the power COUPEL LE COURANT!STROMABSHALTEN!CORTE CORRIENT
1. please retain these installation instructions for future
reference
2. Make sure the lights are turned off and fully energized. Before
installing or replacing lights
3. This product must be installed by a qualified electrician in
accordance with current IEE regulations
4. Checking that there is adequate free air ventilation around the
fitting .Select a suitable mounting location to install the
luminaire,(see reverse of this leaflet for further details)
5. cut a suitable size hole in the ceiling
6.Attach the bracket and connection to the luminaire body
Terminate the cable into the connector block ,Ensure that the
fittings are grounded
RATINGS
1. This fitting can be used with 220- 240V GU10 lamps
2. Fire rated versions are of class 1 construction and must be
earthed
3. Non fire rated versions are of class 2 construction and double
insulated
4. CE approved
Style | Fire-Rated Led Downlighs |
Material | Die-cast Aluminum |
Size | 90xH63mm |
Cutting | 75mm |
Power | 10 W |
Voltage | AC 220V( ± 10%) |
Model | TD2135 |
Warranty | 3 years |
Certification
FAQ
Q1. How to proceed an order for led light?
A: First let us know your requirements and use. Secondly, we quote
according to your requirements and customer suggestions. Third, the
customer confirms the sample and orders the deposit. Fourth, we
arrange production.
Q2. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production.
Q3: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q4: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control
system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with
new order for small quantity. For defective batch products, we will
repair them and resend them to you or we can discuss the solution
including re-call according to real situation.
